SEMIKRON SKIM909GD066HD 600V 900A Trench IGBT Module

Features


Features

• IGBT 3 Trench Gate Technology

• Solderless sinter technology

• VCE(sat) with positive temperature

coefficient

• Low inductance case

• Insulated by Al2O3 DCB (Direct Copper

Bonded) ceramic substrate

• Pressure contact technology for

thermal contacts

• Spring contact system to attach driver

PCB to the control terminals

• High short circuit capability, self limiting

to 6 x IC

• Integrated temperature sensor

Typical Applications*

• Automotive inverter

• High reliability AC inverter wind

• High reliability AC inverter drives
