TI SN65HVD72 SN65HVD72DR 3.3-V Supply RS-485 With IEC ESD Protection

Features


Small-size VSSOP Packages Save Board Space,

or SOIC for Drop-in Compatibility

Bus I/O Protection

– >±15 kV HBM Protection

– >±12 kV IEC 61000-4-2 Contact Discharge

– >±4 kV IEC 61000-4-4 Fast Transient Burst

Extended Industrial Temperature Range –40°C to 125°C

Large Receiver Hysteresis (80 mV) for Noise Rejection

Low Unit-Loading Allows Over 200 Connected Nodes

Low Power Consumption

Low Standby Supply Current: < 2 µA

ICC < 1 mA Quiescent During Operation

5-V Tolerant Logic Inputs Compatible With

3.3-V or 5-V Controllers

Signaling Rate Options Optimized for:250 kbps, 20 Mbps, 50 Mbps
