TI SN65LVDS1 SN65LVDS1DBVR Differential Line Drivers and Receiver

Features


Meets or Exceeds the ANSI TIA/EIA-644 Standard

Designed for Signaling Rates (1) up to

630 Mbps for Drivers

400 Mbps for Receivers

Operates From a 2.4-V to 3.6-V Supply

Available in SOT-23 and SOIC Packages

Bus-Terminal ESD Exceeds 9 kV

Low-Voltage Differential Signaling With Typical

Output Voltages of 350 mV standard and provide a minimum differential output Into a 100-Ω Load

Propagation Delay Times

1.7-ns Typical Driver

2.5-ns Typical Receiver

Power Dissipation at 200 MHz

– 25 mW Typical Driver

– 60 mW Typical Receiver
