INTEL U87C196MC INDUSTRIAL MOTOR CONTROL MICROCONTROLLER

Features


FEATURES

High-Performance CHMOS 16-Bit CPU

16 Kbytes of On-Chip OTPROM/

Factory-Programmed OTPROM

488 bytes of On-Chip Register RAM

Register to Register Architecture

Up to 53 I/O Lines

Peripheral Transaction Server (PTS)

with 11 Prioritized Sources

Event Processor Arra(EPA)

Ð 4 High Speed Capture/Compare

Modules

Ð 4 High Speed Compare Modules

Extended Temperature Standard

Two 16-Bit Timers with Quadrature

Decoder Input

3-Phase ComplementarWaveform

Generator

13 Channel 8/10-Bit A/D with Sample/

Hold with Zero Offset Adjustment H/W

14 Prioritized Interrupt Sources

Flexible 8-/16-Bit External Bus

1.75 ms 16 x 16 Multiply

3 ms 32/16 Divide

Idle and Power Down Modes
