AVAGO ACPF-7005 PCS (A-G) UMTS Band 2 Tx Bandpass Filter

Features


FEATURES

50 Ω Input/Output

• High rejection enables elimination of switches

• Miniature Size

– 1.6 x 2.0 mm size

– 1.1 mm Max Height

• High Power Rating

– +30 dBm Abs Max Tx Power

• Environmental

– RoHS 6 Compliant

– Halogen free

– TBBPA Free

Specifications

• Performance guaranteed –10° to +85°C

– Tx Band Insertion Loss: 3.5 dB Max

– Rx Band Rejection: 33 dB Min
