AD AD9269 AD9269BCPZ-80 1.8 V Dual Analog to Digital Converter

Features


FEATURES

1.8 V analog supply operation

1.8 V to 3.3 V output supply

Integrated quadrature error correction (QEC)

SNR

77.6 dBFS at 9.7 MHz input

71 dBFS at 200 MHz input

SFDR

93 dBc at 9.7 MHz input

80 dBc at 200 MHz input

Low power

44 mW per channel at 20 MSPS

100 mW per channel at 80 MSPS

Differential input with 700 MHz bandwidth

On-chip voltage reference and sample-and-hold circuit

2 V p-p differential analog input

DNL = −0.5/+1.1 LSB

Serial port control options

Offset binary, gray code, or twos complement data format

Optional clock duty cycle stabilizer (DCS)

Integer 1-to-6 input clock divider

Data output multiplex option

Built-in selectable digital test pattern generation

Energy-saving power-down modes

Data clock output (DCO) with programmable clock and

data alignment

APPLICATIONS

Communications

Diversity radio systems

Multimode digital receivers

GSM, EDGE, W-CDMA, LTE, CDMA2000, WiMAX, TD-SCDMA

I/Q demodulation systems

Smart antenna systems

Battery-powered instruments

Handheld scope meters

Portable medical imaging

Ultrasound

Radar/LIDAR
