NCV8703 NCV8703MX28TCG 300mA Ultra-Low Quiescent Current,Ultra-Low Noise,Low Dropout Regulator

Features


FEATURES

Operating Input Voltage Range: 2.0 V to 5.5 V

Available in Fixed Voltage Options: 0.8 to 3.5 V

Contact Factory for Other Voltage Options

Ultra−Low Quiescent Current of Typ. 12 A

Ultra−Low Noise: 13 VRMS from 100 Hz to 100 kHz

Very Low Dropout: 180 mV Typical at 300 mA

2% Accuracy Over Load/Line/Temperature

High PSRR: 68 dB at 1 kHz

Internal Soft−Start to Limit the Turn−On Inrush Current

Thermal Shutdown and Current Limit Protections

Stable with a 1 F Ceramic Output Capacitor

Available in TSOP−5 and XDFN 1.5 x 1.5 mm Package

Active Output Discharge for Fast Turn−Off

NCV Prefix for Automotive and Other Applications Requiring

Unique Site and Control Change Requirements; AEC−Q100

Qualified and PPAP Capable

These are Pb−Free Devices

Typical Applications

Satellite Radio Receivers, GPS

Rear View Camera, Electronic Mirrors, Lane Change Detectors

Portable Entertainment Systems

Other Battery Powered Applications
