TPS727185 TPS727185YFFR LDO Voltage Regulators 200mAUltralow IQ Fast Trans RespRF

Features


FEATURES

Very Low Dropout:

65 mV Typical at 100 mA

130 mV Typical at 200 mA

163 mV Typical at 250 mA

2% Accuracy Over Load, Line, Temperature

Ultralow IQ: 7.9 µA

Excellent Load Transient Performance:±50 mV for

200 mA Loading and Unloading Transient

Available in Fixed-Output Voltages From 0.9 V to

5 V Using Innovative Factory EEPROM Programming

High PSRR: 70 dB at 1 kHz

Stable with a 1.0-µF Ceramic Capacitor

Thermal Shutdown and Overcurrent Protection

Available in 4-Ball, 0.4-mm Pitch Wafer-Level

Chip Scale and 1.5-mm × 1.5-mm SON Packages

Applications

power-sensitive applications
