MC56F8013 MC56F8013VFAE 16-bit Digital Signal Controllers

Features


Features

Digital Signal Controller Core

Efficient 16-bit 56800E family Digital Signal Controller (DSC) engine with dual Harvard architecture

As many as 32 Million Instructions Per Second (MIPS) at 32MHz core frequency

Single-cycle 16 × 16-bit parallel Multiplier-Accumulator (MAC)

Four 36-bit accumulators, including extension bits

32-bit arithmetic and logic multi-bit shifter

Parallel instruction set with unique DSP addressing modes

Hardware DO and REP loops

Three internal address buses

Four internal data buses

Instruction set supports both DSP and controller functions

Controller-style addressing modes and instructions for compact code

Efficient C compiler and local variable support

Software subroutine and interrupt stack with depth limited only by memory

JTAG/Enhanced On-Chip Emulation (OnCE) for unobtrusive, processor speed-independent, real-time

debugging
