CY8CLED04 CY8CLED04-68LFXI LED Lighting Systems on a Chip SoC

Features


Description

Core:    M8C

Data Bus Width: 8 bit

Maximum Clock Frequency:   24 MHz

Program Memory Size:   16 kB

Data RAM Size:  1 kB

ADC Resolution: 12 bit

Operating Supply Voltage:    3 V to 5.25 V

Maximum Operating Temperature:    + 85 C

Mounting Style:  SMD/SMT

Package / Case: QFN-68

Brand:   Cypress Semiconductor

DAC Resolution: 8 bit, 9 bit

Data RAM Type: SRAM

Data ROM Size:  2 kB

Data ROM Type:      EEPROM

Height:  1 mm

Interface Type:  API, DMX512, I2C, SPI, UART, USB

Length: 8 mm

Minimum Operating Temperature:     - 40 C

Number of I/Os:      56 I/O

Number of Timers/Counters: 1 x 8 bit to 31 bit

Operating Supply Current:     27 mA

Program Memory Type:  Flash
