504528-0892 5045280892 Memory Socket, Bar-Push 504528 Series, Micro SD, 8 Contacts

Features


Key Features

General

Product Family Memory Card Sockets

Series 504528

Comments Tray is customer sourced.

Material - Contact Copper Alloy

Material - Shell Stainless Steel

Product Name microSD* Card

Style Pin-Eject

UPC 887191607818

Physical

Card Detection Switch Open

Card Entry Location Top

Circuits (Loaded) 8

Circuits (maximum) 8

Color - Resin Black

Durability (mating cycles max) 3000

Ejector Button Side Right

Material - Plating Mating Gold over Nickel

Material - Resin Liquid Crystal Polymer

Net Weight 508.940/mg

PCB Retention Yes

Packaging Type Embossed Tape on Reel

Pitch - Mating Interface 1.00mm

Temperature Range - Operating -25°C to +85°C

Termination Interface: Style Surface Mount

Electrical

Current - Maximum per Contact 0.5A

Voltage - Maximum 10V AC (RMS)/DC
