ADG749 ADG749BKSZ CMOS 1.8V to 5.5V, 2.5Ω 2:1 Mux/SPDT Switch IC

Features


Features

1.8 V to 5.5 V single supply

5 Ω (maximum) on resistance

0.75 Ω (typical) on resistance flatness

Automotive temperature range: −40°C to +125°C

–3 dB bandwidth > 200 MHz

Rail-to-rail operation

6-lead SC70 package

Fast switching times

tON = 12 ns

tOFF = 6 ns

Typical power consumption (< 0.01 μW)

TTL/CMOS compatible

APPLICATIONS

Battery-powered systems

Communication systems

Sample-and-hold systems

Audio signal routing

Video switching

Mechanical reed relay replacement
