Manufacturer Part |
|
The L6235 device is a DMOS fully integrated 3-phase motor driver with overcurrent protection. |
|
Motor / Motion / Ignition Controllers & Drivers |
|
Datasheet |
Details |
FEATURES Operating supply voltage from 8 to 52 V 5.6 A output peak current (2.8 A DC) RDS(ON) 0.3 typ. value at Tj= 25 °C Operating frequency up to 100 KHz Non-dissipative over current detection and protection Diagnostic output Constant t OFF PWM current controller Slow decay synchr. rectification 60° and 120° hall effect decoding logic Brake function Tachometer output for speed loop Cross conduction protection Thermal shutdown Under voltage lockout Integrated fast freewheeling diodes |
