Manufacturer Part |
|
IC GAS GAUGE LI-ION/POL 10CSP Battery Battery Monitor IC 10-CSP (2.01x1.37) |
|
Mobile phones, multimedia players, digital cameras Portable medical equipment |
|
Datasheet |
Details |
FEATURES OptimGaugeTM algorithm 0.25% accuracy battery voltage monitoring Coulomb counter and voltage-mode gas gauge operations Robust initial open-circuit-voltage (OCV)measurement at power up Programmable low battery alarm Internal temperature sensor Battery swap detection Low power: 45 µA in power-saving mode, 2 µA max in standby mode Micro-sized packages: – 1.4 x 2.0 mm 10-bump CSP package – 2.0 x 3.0 mm DFN10 package The STC3115 includes the hardware functions required to implement a low-cost gas gauge for battery monitoring. The STC3115 uses current sensing, Coulomb counting and accurate measurements of the battery voltage to estimate the state-of-charge (SOC) of the battery. An internal temperature sensor simplifies implementation of temperature compensation. |
