HMC311ST89E HMC311ST89ETR RF Amplifier IC General Purpose

Details


Product Category:RF Amplifier

Manufacturer:    Analog Devices Inc.

RoHS:   RoHS Compliant Details

Type:   HBT Gain Block

Operating Frequency:     DC to 6 GHz

Gain:16 dB

NF - Noise Figure:4.5 dB

P1dB - Compression Point:15.5 dBm

OIP3 - Third Order Intercept: 31.5 dBm

Operating Supply Voltage:5 V

Operating Supply Current:125 mA

Minimum Operating Temperature:- 40 C

Maximum Operating Temperature:+ 85 C

Mounting Style:SMD/SMT

Package / Case:SOT-89-3

Packaging:Reel

Amplifier Type:LNA

Brand:   Analog Devices / Hittite

Frequency Range:71 GHz to 86 GHz

Input Return Loss:14 dB

Number of Channels:     1 Channel

Pd - Power Dissipation:0.34 W

Product:InGaP/GaAs HBT

Series:  HMC311

Factory Pack Quantity:500

Technology:GaAs InGaP

Unit Weight:0.004603 oz

The HMC311ST89(E) is a GaAs InGaP Heterojunction Bipolar Transistor (HBT) Gain Block MMIC SMT DC to 6 GHz amplifier.
