Manufacturer Part |
|
Supervisor Push-Pull, Totem Pole 3 Channel 8-SOIC IC SUPERVISOR TRPL PROC 8-SOIC |
|
Supervising DSPs/microcontrollers Industrial and portable equipment Wireless systems Notebook/desktop computers |
|
Datasheet |
Details |
Product Category:Supervisory Circuits Manufacturer: Analog Devices Inc. RoHS: RoHS Compliant Details Type: Voltage Supervisory Package / Case:SOIC-8 Threshold Voltage:0.6 V, 2.93 V Number of Inputs Monitored: 3 Input Output Type:Push-Pull Manual Reset: Manual Reset Battery Backup Switching:No Backup Supply Voltage - Max: 5.5 V Maximum Operating Temperature:+ 85 C Series: ADM13307 Packaging:Reel Packaging:MouseReel Packaging:Cut Tape Brand: Analog Devices Minimum Operating Temperature:- 40 C Operating Supply Current:40 uA Factory Pack Quantity:1000 Supply Voltage - Min: 2 V Watchdog Timers:No Watchdog Unit Weight:0.019048 oz
FEATURES Triple supervisory circuits Supply voltage range of 2.0 V to 5.5 V Pretrimmed threshold options: 1.8 V, 2.5 V, 3.3 V, and 5 V Adjustable 0.6 V and 1.25 V voltage references Maximum supply current of 40 μA 140 ms (minimum) reset timeout RESET valid from VDD ≥ 1.1 V Push-pull RESET and RESET outputs 8-lead, narrow body SOIC package Temperature range: −40°C to +85°C |
