LTM4630 LTM4630EV Dual 18A or Single 36A DC/DC µModule Regulator

Details


FEATURES

Dual 18A or Single 36A Output

Wide Input Voltage Range: 4.5V to 15V

Output Voltage Range: 0.6V to 1.8V

±1.5% Maximum Total DC Output Error Over Line,Load and Temperature

Differential Remote Sense Amplifier

Current Mode Control/Fast Transient Response

Adjustable Switching Frequency

Overcurrent Foldback Protection

Multiphase Parallel Current Sharing with Multiple LTM4630s Up to 144A

Frequency Synchronization

Internal Temperature Monitor

Pin Compatible with the LTM4620 and LTM4620A (Dual 13A, Single 26A) and LTM4628 (Dual 8A, Single 16A)

Selectable Burst Mode® Operation

Soft-Start/Voltage Tracking

Output Overvoltage Protection

16mm × 16mm × 4.41mm LGA and 16mm × 16mm ×5.01mm BGA Packages

The LTM4630 is a dual 18A or single 36A output switching mode step-down DC/DC µModule® (micromodule) regulator
