Manufacturer Part |
|
|
ESD Suppressors / TVS Diodes 4Chnl U-Lo Capacitnc IEC ESD Prot Diodes |
|
|
HDMI 1.4b HDMI 2.0 USB 3.0 MHL LVDS Interfaces DisplayPort PCI-Express® eSata Interfaces V-by-One® HS |
|
|
Datasheet |
|
Details |
|
Features • IEC 61000-4-2 Level 4 ESD Protection – ±12-kV Contact Discharge – ±15-kV Air Gap Discharge • IEC 61000-4-4 EFT Protection– 80 A (5/50 ns) • IEC 61000-4-5 Surge Protection– 2.5 A (8/20 µs) • IO Capacitance 0.42 pF to 0.5 pF (Typical) • DC Breakdown Voltage 6.5 V (Minimum) • Ultra low Leakage Current 10 nA (Maximum) • Low ESD Clamping Voltage • Industrial Temperature Range: –40°C to +125°C • Easy Straight-Through Routing Packages
The TPDxE05U06 is a family of unidirectional Transient Voltage Suppressor (TVS) based Electrostatic Discharge (ESD) protection diodes with ultra-low capacitance. |
