Manufacturer Part |
|
|
Linear Voltage Regulator IC Positive Adjustable 1 Output 0.8 V ~ 3.6 V 3A 20-VQFN (5x5) |
|
|
FPGA Applications DSP Core and I/O Voltages Servers Post-Regulation Applications Applications with Special Start-Up Time or Sequencing Requirements |
|
|
Datasheet |
|
Details |
|
Manufacturer: Texas Instruments Product Category: LDO Voltage Regulators Mounting Style: SMD/SMT Package / Case: VQFN-20 Output Voltage: 798mV to 3.6V Output Current: 3A Number of Outputs: 1 Output Polarity: Positive Input Voltage MAX: 5.5V Input Voltage MIN: 0.8V Output Type: Adjustable Minimum Operating Temperature: - 40 C Maximum Operating Temperature: + 125 C Load Regulation: 0.09 %/A Series: TPS74901 Dropout Voltage: 120mV Packaging: Cut Tape Packaging: Reel Height: 0.9mm Length: 5mm Operating Temperature Range: - 40 C to + 125 C Width: 5mm Dropout Voltage - Max: 240mV at 3A Voltage Regulation Accuracy: 0.5% CNHTS: 8542319000 Development Kit: TPS74901EVM-210 HTS Code: 8542390001 Ib - Input Bias Current: 3mA Line Regulation: 0.03%/V MXHTS: 85423999 Operating Supply Current: 3mA Pd - Power Dissipation: 2.74W Product Type: LDO Voltage Regulators Reference Voltage: 0.806V Factory Pack Quantity: 3000 Subcategory: PMIC - Power Management ICs TARIC: 8542399000 The TPS74901 low-dropout (LDO) linear regulator provides an easy-to-use, robust power management solution for a wide variety of applications. |
