New and original TOSHIBA TCR5AM12 500mA CMOS ultra-low dropout voltage regulator for sale in large quantities, the TCR5AM series are CMOS single output voltage regulators with on/off control inputs featuring ultra-low dropout voltage, low inrush current and fast load transient response.
Supplier: Mingjiada
Model: TCR5AM12
Batch: 1729+
Package: DFNB5
Type: Low Dropout Regulator
Series: TCR5AM
Output voltage: 1.2 V
Output current: 500 mA
Number of outputs: 1 Output
Static current: 40 uA
Input voltage (min.): 1.3 V
Input voltage (max): 5.5 V
PSRR/ripple rejection - typical: 70 dB
Output type: Fixed
Min. operating temperature: - 40 C
Max. operating temperature: + 85 C
Return voltage: 230 mV
Return voltage - max: 270 mV
Line regulation: 1 mV
Load regulation: 15 mV
Pd - power dissipation: 600 mW
Factory packed quantity: 5000
