MIT PM50B6LA060 FLAT-BASE TYPE INSULATED PACKAGE New and original have in stock
| Part number | Brand | Date | QTY | Package | Remarks |
PM50B6LA060 |
MIT |
13+ROHS | 9900 | IGBT MODULE |
Original have in stock |
FEATURE
Adopting new 5th generation IGBT (CSTBTTM) chip, which
performance is improved by 1µm fine rule process.
For example, typical Vce(sat)=1.55V @Tj=125°C
Over-temperature protection by detecting Tj of the CSTBTTM
chips and error output is possible from all each conservation upper and lower arm of IPM.
New small package
Reduce the package size by 10%, thickness by 22% from
S-DASH series.
• 2φ 50A, 600V Current-sense IGBT type inverter
• 50A, 600V Current-sense Chopper IGBT
• Monolithic gate drive & protection logic
• Detection, protection & status indication circuits for, shortcircuit, over-temperature & under-voltage (P-Fo available
from upper arm devices)
• UL Recognized Yellow Card No.E80276(N)
| Datasheets | PM50B6L(A,B)060 |
|---|---|
| Standard Package | 10 |
| Category | Discrete Semiconductor Products |
| Family | Power Drivers - Modules |
| Series | Intellimod™ |
| Type | IGBT |
| Configuration | H-Bridge |
| Current | 50A |
| Voltage | 600V |
| Voltage - Isolation | 2500VDC |
| Package / Case | Module |
PHOTO:
