TI LM1894MX IC NOISE REDUCT SYS DYNAM 14SOIC MJD New in stock

Part number	Brand	Date	QTY	Package	Remarks
LM1894MX	TI	13+ROHS	7500	SOP14	Original have in stock

PDF datasheet:

The LM1894 is a stereo noise reduction circuit for use with audio playback systems. The DNR system is non-complementary, meaning it does not require encoded source material. The system is compatible with virtually all prerecorded tapes and FM broadcasts. Psychoacoustic masking, and an adaptive bandwidth scheme allow the DNR to achieve 10 dB of noise reduction. DNR can save circuit board space and cost because of the few additional components required.

Features

Non-complementary noise reduction, “single ended”

Low cost external components, no critical matching

Compatible with all prerecorded tapes and FM

10 dB effective tape noise reduction CCIR/ARM weighted

Wide supply range, 4.5V to 18V

1 Vrms input overload

Applications

Automotive radio/tape players

Compact portable tape players

Quality HI-FI tape systems

VCR playback noise reduction

Video disc playback noise reduction

Datasheet

Datasheets	LM1894
Product Photos	14-SOIC 14-TSSOPa
Standard Package	2,500
Category	Integrated Circuits (ICs)
Family	Linear - Audio Processing
Series	-
Packaging	Tape & Reel (TR)
Type	Dynamic Noise Reduction
Applications	Automotive Systems, Players, TV
Mounting Type	Surface Mount
Package / Case	14-SOIC (0.154", 3.90mm Width)
Supplier Device Package	14-SOICN
Dynamic Catalog	Audio Processing
For Use With	LM1894MTBD-ND - BOARD EVALUATION LM1894
Other Names	LM1894MX LM1894MX/NOPB 296-35393-2 LM1894MX LM1894MX-ND LM1894MX/NOPB-ND LM1894MXNOPB
