Microsemi APT30D120BG APT30D120 ULTRAFAST SOFT RECOVERY RECTIFIER DIODE
| Part number | Brand | Date | QTY | Package | Remarks |
| APT30D120BG | Microsemi | 14+ROHS | 7500 | TO-247 |
Original have in stock |
PDF datasheet：
PRODUCT FEATURES
Ultrafast Recovery Times
Soft Recovery Characteristics
Popular TO-247 Package or Surface Mount D3PAK Package
Low Forward Voltage
Low Leakage Current
Datasheet
| Datasheets | APT30D120B,S(G) Power Products Catalog |
|---|---|
| Product Photos | APT30D120BG |
| Product Training Modules | Diode Overview |
| Catalog Drawings | TO-247 2 Pin Front |
| Standard Package | 30 |
| Category | Discrete Semiconductor Products |
| Family | Diodes, Rectifiers - Single |
| Series | - |
| Packaging | Tube |
| Diode Type | Standard |
| Voltage - DC Reverse (Vr) (Max) | 1200V (1.2kV) |
| Current - Average Rectified (Io) | 30A |
| Voltage - Forward (Vf) (Max) @ If | 2.5V @ 30A |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Reverse Recovery Time (trr) | 370ns |
| Current - Reverse Leakage @ Vr | 250µA @ 1200V |
| Capacitance @ Vr, F | - |
| Thermal Resistance | 0.61°C/W Jc |
| Mounting Type | Through Hole, Radial |
| Package / Case | TO-247-2 |
| Supplier Device Package | TO-247 |
| Operating Temperature - Junction | -55°C ~ 175°C |
| Dynamic Catalog | Standard Diode |
| Other Names | APT30D120BGMI APT30D120BGMI-ND |
Picture：
