NS DS90CF386MTDX DS90CF386 IC RVR LVDS FPD 3.3V 56-TSSOP
| Part number | Brand | Date | QTY | Package | Remarks |
| DS90CF386MTDX | NS | 14+ROHS | 7500 | TSSOP-56 |
Original have in stock |
Features
20 to 85 MHz shift clock support
Rx power consumption <142 mW (typ) @85MHz Grayscale
Rx Power-down mode <1.44 mW (max)
ESD rating >7 kV (HBM), >700V (EIAJ)
Supports VGA, SVGA, XGA and Single Pixel SXGA.
PLL requires no external components
Compatible with TIA/EIA-644 LVDS standard
Low profile 56-lead or 48-lead TSSOP package
DS90CF386 also available in a 64 ball, 0.8mm fine pitch ball grid array (FBGA) package
PDF datasheet:
SPECIFICATIONS
| Mfr Package Description | LOW PROFILE, PLASTIC, TSSOP-56 |
| Lead Free | Yes |
| EU RoHS Compliant | Yes |
| China RoHS Compliant | Yes |
| Status | TRANSFERRED |
| Package Shape | RECTANGULAR |
| Package Style | SMALL OUTLINE, THIN PROFILE, SHRINK PITCH |
| Surface Mount | Yes |
| Terminal Form | GULL WING |
| Terminal Pitch | 0.5000 mm |
| Terminal Finish | TIN |
| Terminal Position | DUAL |
| Number of Functions | 4 |
| Number of Terminals | 56 |
| Package Body Material | PLASTIC/EPOXY |
| Temperature Grade | COMMERCIAL |
| Operating Temperature-Max | 70 Cel |
| Operating Temperature-Min | -10 Cel |
| Supply Voltage1-Max (Vsup) | 3.6 V |
| Supply Voltage1-Min (Vsup) | 3 V |
| Supply Voltage1-Nom (Vsup) | 3.3 V |
| Interface IC Type | LINE RECEIVER |
| Interface Standard | EIA-644; TIA-644 |
| Input Characteristics | DIFFERENTIAL |
| Receiver Number of Bits | 4 |
Picture:
