Panasonic ETQP5M220YFK ETQP5M220 Power Choke Coil for Automotive application
| Part number | Brand | Date | QTY | Package | Remarks |
| ETQP5M220YFK | Panasonic | 14+ROHS | 7500 | SMD |
Original have in stock |
■ Features
● High heat resistance : Operation up to 150 °C
● High-reliability : High vibration tolerance in high temperature due to newly developed integral construction and severe condition of automotive application is cleared
● High bias current : Excellent inductance stability by using ferrous alloy magnetic material(Fig.1)
● Temp. stability : Excellent inductance stability in wide temp. range (Fig.1)
● Low buzz noise : New metal composite core technology
● High effi ciency : Low RDC of winding and low eddy-current loss of the core
■ Standard Packing Quantity
● 500 pcs./Reel
Specification：
| Datasheets | ETQP5M220YFK  |
|---|---|
| Packaging | Tape & Reel (TR) |
| Type | Wirewound |
| Material - Core | Metal Composite |
| Inductance | 22.7µH |
| Tolerance | ±20% |
| Current Rating | 1.6A |
| Current - Saturation | - |
| Shielding | Unshielded |
| DC Resistance (DCR) | 63 mOhm |
| Q @ Freq | - |
| Frequency - Self Resonant | - |
| Operating Temperature | -40°C ~ 150°C |
| Frequency - Test | - |
| Mounting Type | Surface Mount |
| Package / Case | Non Standard |
| Size / Dimension | 0.335" L x 0.315" W (8.50mm x 8.00mm) |
| Height - Seated (Max) | 0.213" (5.40mm) |
Picture：
