Infineon BTS462T BTS462 Smart High-Side Power Switch
| Part number | Brand | Date | QTY | Package | Remarks |
| BTS462T | Infineon | 14+ROHS | 7500 | TO-252 |
Original have in stock |
Features
•Overload protection
• Current limitation
•Short circuit protection
•Thermal shutdown with restart
•Overvoltage protection (including load dump)
•Fast demagnetization of inductive loads
• Reverse battery protection with external resistor
•CMOS compatible input
•Loss of GND and loss of Vbbprotection
•ESD - Protection
•Very low standby current
Application
•All types of resistive, inductive and capacitive loads
•µC compatible power switch for 12 V and 24 V DC applications
•Replaces electromechanical relays and discrete circuits
Specification
| Datasheets | BTS462T  |
|---|---|
| Packaging | Tape & Reel (TR) |
| Type | High Side |
| Input Type | Non-Inverting |
| Number of Outputs | 1 |
| On-State Resistance | 70 mOhm |
| Current - Output / Channel | 4.4A |
| Current - Peak Output | 14A |
| Voltage - Supply | 5 V ~ 34 V |
| Operating Temperature | -40°C ~ 150°C |
| Mounting Type | Surface Mount |
| Package / Case | TO-252-5, DPak (4 Leads + Tab), TO-252AD |
