Littelfuse S8055R SCR NON-ISOLATE 800V 55A TO220AB
| Part number | Brand | Date | QTY | Package | Remarks |
| S8055R | Littelfuse | 14+ROHS | 7500 | TO-220 |
Original have in stock |
Features
• Electrically-isolated package
• High voltage capability — 200 V to 1000 V
• High surge capability — up to 950 A
• Glass-passivated chip
Specification
| Datasheets | S8055R |
|---|---|
| Packaging | Bulk |
| Voltage - Off State | 800V |
| Voltage - Gate Trigger (Vgt) (Max) | 1.5V |
| Current - Gate Trigger (Igt) (Max) | 40mA |
| Voltage - On State (Vtm) (Max) | 1.8V |
| Current - On State (It (AV)) (Max) | 35A |
| Current - On State (It (RMS)) (Max) | 55A |
| Current - Hold (Ih) (Max) | 60mA |
| Current - Off State (Max) | 20µA |
| Current - Non Rep. Surge 50, 60Hz (Itsm) | 550A, 650A |
| SCR Type | Standard Recovery |
| Operating Temperature | -40°C ~ 125°C |
| Mounting Type | Through Hole |
| Package / Case | TO-220-3 |
