TI TLK1102ERGER 11.3-Gbps Dual-Channel Cable and PC Board Equalizer
| Part number | Brand | Date | QTY | Package | Remarks |
| TLK1102ERGER | TI | 14+ROHS | 7500 | QFN-24 |
Original have in stock |
Features
•Dual-Channel Multi-Rate Operation up to 24-Pin QFN Package 11.3Gbps
• Two-Wire Serial Interface (with 8 Selectable Device Addresses) or Device Pin Control
• Compensates for up to 30dB Loss on the Receive Side and up to 7dB Loss on the Transmit Side at 5.65GHz Systems
• Adjustable Input Equalization Level
• Adjustable Output De-Emphasis: 0 - 7dB
• Adjustable Input Bandwidth: 4.5 - 11GHz
• Adjustable CML Output Swing: 225 - Active Cable Assemblies 1200mVp-p
• Loss of Signal (LOS) Detection
• Output Disable with Selectable Auto-Squelch Function
• Output Polarity Switch
• Excellent High Frequency Input and Output Return Loss
• Surface Mount Small Footprint 4-mm × 4-mm 24-Pin QFN Package
• Single 3.3V Supply
• -40°C to 100°C Operation (Lead Temperature)
Specification
| Datasheets | TLK1102ERGER |
|---|---|
| Packaging | Tape & Reel (TR) |
| Applications | Networking |
| Interface | 2-Wire Serial |
| Voltage - Supply | 2.95 V ~ 3.6 V |
| Package / Case | 24-VFQFN Exposed Pad |
| Supplier Device Package | 24-VQFN (4x4) |
| Mounting Type | Surface Mount |
