TI LMV771MG LMV771 Single/Dual/Quad, Low Offset, Low Noise, RRO Operational Amplifiers
| Part number | Brand | Date | QTY | Package | Remarks |
| LMV771MG | TI | 14+ROHS | 7500 | SC70-5 |
Original have in stock |
Features
(Typical 2.7V Supply Values; Unless Otherwise Noted)
Guaranteed 2.7V and 5V specifications
Maximum VOS (LMV771) 850µV (limit)
Voltage Noise
— f = 100Hz 12.5nV/
— f = 10kHz 7.5nV/
Rail-to-Rail output swing
— w/600Ω load 100mV from rail
— w/2kΩ load 50mV from rail
Open loop gain w/2kΩ load 100dB
VCM 0 to V+ -0.9V
Supply current (per amplifier) 550µA
Gain bandwidth product 3.5MHz
Temperature range −40˚C to 125˚C
Applications
Transducer amplifier
Instrumentation amplifier
Precision current sensing
Data acquisition systems
Active filters and buffers
Sample and hold
Portable/battery powered electronics
| Datasheets | LMV771MG |
|---|---|
| Amplifier Type | General Purpose |
| Number of Circuits | 1 |
| Output Type | Rail-to-Rail |
| Slew Rate | 1.4 V/µs |
| Gain Bandwidth Product | 3.5MHz |
| -3db Bandwidth | - |
| Current - Input Bias | 0.23pA |
| Voltage - Input Offset | 250µV |
| Current - Supply | 600µA |
| Current - Output / Channel | 75mA |
| Voltage - Supply, Single/Dual (±) | 2.7 V ~ 5.5 V |
| Operating Temperature | -40°C ~ 125°C |
| Mounting Type | Surface Mount |
| Package / Case | 6-TSSOP (5 Lead), SC-88A, SOT-353 |
