Maxim MAX3443EASA MAX3443 Single Transmitter/Receiver RS-485 8-Pin SOIC N T/R
Part number：MAX3443EASA
Brand：Maxim
Package：SOP-8
Remarks：New and Original have in stock
PDF:
Features
♦ ±15kV ESD Protection
♦ ±60V Fault Protection
♦ Guaranteed 10Mbps Data Rate(MAX3441E/MAX3443E)
♦ Hot Swappable for Telecom Applications
♦ True Fail-Safe Receiver Inputs
♦ Enhanced Slew-Rate-Limiting Facilitates Error-Free Data Transmission(MAX3440E/MAX3442E/MAX3444E)
♦ Allow Up to 128 Transceivers on the Bus
♦ -7V to +12V Common-Mode Input Range
♦ Automotive Temperature Range (-40°C to +125°C)
♦ Industry-Standard Pinout
| Type | Transceiver |
|---|---|
| Protocol | RS485 |
| Number of Drivers/Receivers | 1/1 |
| Duplex | Half |
| Receiver Hysteresis | 25mV |
| Data Rate | 10Mbps |
| Voltage - Supply | 4.75 V ~ 5.25 V |
| Operating Temperature | -40°C ~ 125°C |
| Mounting Type | Surface Mount |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) |
