VISHAY IRF9640STRLPBF IRF9640 MOSFET P-CH 200V 11A D2PAK
| Part number | Brand | Date | QTY | Package | Remarks |
| IRF9640STRLPBF | VISHAY | 14+ROHS | 7500 | TO-263 |
Original have in stock |
FEATURES
• Halogen-free According to IEC 61249-2-21Definition
• Surface Mount
• Available in Tape and Reel
• Dynamic dV/dt Rating
• Repetitive Avalanche Rated
• P-Channel
• Fast Switching
• Ease of Paralleling
• Compliant to RoHS Directive 2002/95/EC
Specification
| Datasheets | IRF9640STRLPBF  |
|---|---|
| Packaging | Tape & Reel (TR) |
| FET Type | MOSFET P-Channel, Metal Oxide |
| FET Feature | Standard |
| Drain to Source Voltage (Vdss) | 200V |
| Current - Continuous Drain (Id) @ 25°C | 11A (Tc) |
| Rds On (Max) @ Id, Vgs | 500 mOhm @ 6.6A, 10V |
| Vgs(th) (Max) @ Id | 4V @ 250µA |
| Gate Charge (Qg) @ Vgs | 44nC @ 10V |
| Input Capacitance (Ciss) @ Vds | 1200pF @ 25V |
| Power - Max | 3W |
| Mounting Type | Surface Mount |
| Package / Case | TO-263-3, D²Pak (2 Leads + Tab), TO-263AB |
