ST L3G4200DTR L3G4200 IC GYROSCOPE MEMS 3AXIS LP 16LGA
| Part number | Brand | Date | QTY | Package | Remarks |
| L3G4200DTR | ST | 14+ROHS | 7500 | LGA-16 |
Original have in stock |
Key Features
Three selectable full scales (250/500/2000 dps)
I2C/SPI digital output interface
16 bit-rate value data output
8-bit temperature data output
Two digital output lines (interrupt and data ready)
Integrated low- and high-pass filters with user-selectable bandwidth
Ultra-stable over temperature and time
Wide supply voltage: 2.4 V to 3.6 V
Low voltage-compatible IOs (1.8 V)
Embedded power-down and sleep mode
Embedded temperature sensor
Embedded FIFO
High shock survivability
Extended operating temperature range (-40 °C to +85 °C)
ECOPACK® RoHS and “Green” compliant
| Datasheets | L3G4200DTR |
|---|---|
| Range °/s | ±250°/s, ±500°/s, ±2000°/s |
| Sensitivity | 70m°/s, 17.5m°/s, 8.75m°/s |
| Typical Bandwidth | 800Hz, 400Hz, 200Hz, 100Hz |
| Voltage - Supply | 2.4 V ~ 3.6 V |
| Current - Supply | 6.1mA |
| Output Type | I²C, SPI |
| Operating Temperature | -40°C ~ 85°C |
| Package / Case | 16-TFLGA |
