TI SN74LVC1G04DBVR SN74LVC1G04 SINGLE INVERTER SOT23-5
| Part number | Brand | Date | QTY | Package | Remarks |
| SN74LVC1G04DBVR | TI | 14+ROHS | 7500 | SOT23-5 |
Original have in stock |
Features
Available in the Ultra-Small 0.64-mm2
Package (DPW) with 0.5-mm Pitch
Supports 5-V VCC Operation
Inputs Accept Voltages up to 5.5 V Allowing Down Translation to VCC
Max tpd of 3.3 ns at 3.3-V
Low Power Consumption, 10-μA Max ICC
±24-mA Output Drive at 3.3-V
Ioff Supports Live-Insertion, Partial-Power-Down Mode, and Back-Drive Protection
Latch-Up Performance Exceeds 100 mA
Per JESD 78, Class II
ESD Protection Exceeds JESD 22
2000-V Human-Body Model (A114-A)
200-V Machine Model (A115-A)
1000-V Charged-Device Model (C101)
Specification
| Datasheets | SN74LVC1G04DBVR |
|---|---|
| Packaging | Tape & Reel (TR) |
| Logic Type | Inverter |
| Number of Circuits | 1 |
| Number of Inputs | 1 |
| Features | - |
| Voltage - Supply | 1.65 V ~ 5.5 V |
| Current - Quiescent (Max) | 10µA |
| Current - Output High, Low | 32mA, 32mA |
| Logic Level - Low | 0.7 V ~ 0.8 V |
| Logic Level - High | 1.7 V ~ 2 V |
| Max Propagation Delay @ V, Max CL | 3.7ns @ 5V, 50pF |
| Operating Temperature | -40°C ~ 125°C |
| Mounting Type | Surface Mount |
| Supplier Device Package | SOT-23-5 |
