NCT1008CMT3R2G NCT1008 TMP DIO MON/SMBUS 4CH 8WDFN

NCT1008CMT3R2G NCT1008 TMP DIO MON/SMBUS 4CH 8WDFN

Features

• On−Chip and Remote Temperature Sensor

• 0.25°C Resolution/1°C Accuracy on Remote Channel

• 1°C Resolution/1°C Accuracy on Local Channel

• Series Resistance Cancellation Up to 1.5 k

• Extended, Switchable Temperature Measurement Range

0°C to +127°C (Default) or –64°C to +191°C

• Register−Compatible with ADM1032 and ADT7461

• Remote THERM Limit of 108°C

• 2−Wire SMBus/I2C Serial Interface with SMBus Alert Support

• Programmable Over/Undertemperature Limits

• Offset Registers for System Calibration

• Up to Two Overtemperature Fail−Safe THERM Outputs

• Small 8−Lead DFN

• 240 A Operating Current, 5 A Standby Current

• Compatible with 1.8 V Logic

• Pb−Free Packages are Available

Applications

• Smart Phones

• Desktop and Notebook Computers

• Smart Batteries

• Automotive

• Embedded Systems

Datasheet	NCT1008CMT3R2G
Function	Temp Monitoring System (Sensor)
Sensor Type	Internal and External
Sensing Temperature	0°C ~ 127°C, -64°C ~ 191°C
Accuracy	±2.5°C(Max)
Topology	ADC (Sigma Delta), Comparator, Multiplexer, Register Bank
Output Type	I²C/SMBus
Output Alarm	Yes
Output Fan	Yes
Voltage - Supply	2.8 V ~ 3.6 V
Operating Temperature	-40°C ~ 125°C
Mounting Type	Surface Mount
Package / Case	8-WFDFN
