SN75C3221DBR SN75C3221 IC RS232 DRVR/RCVR 1-CH 16-SSOP
| Part number | Brand | Date | QTY | Package | Remarks |
| SN75C3221DBR | TI | 14+ROHS | 7500 | SSOP-16 |
Original have in stock |
Features
Operate With 3-V to 5.5-V VCC Supply
Operate up to 1 Mbit/s
Low Standby Current ...1 µA Typical
External Capacitors ...4 × 0.1 µF
Accepts 5-V Logic Input With 3.3-V Supply
RS-232 Bus-Pin ESD Protection Exceedsb ±15 kV Using Human-Body Model (HBM)
Auto-Powerdown Feature Automatically Disables Drivers for Power Savings
Applications
Battery-Powered, Hand-Held, and Portable Equipment
PDAs and Palmtop PCs
Notebooks, Sub-Notebooks, and Laptops
Digital Cameras
Mobile Phones and Wireless Devices
| Datasheets | SN75C3221DBR |
|---|---|
| Type | Transceiver |
| Protocol | RS232 |
| Number of Drivers/Receivers | 1/1 |
| Duplex | Full |
| Receiver Hysteresis | 500mV |
| Data Rate | 1Mbps |
| Voltage - Supply | 3 V ~ 5.5 V |
| Operating Temperature | 0°C ~ 70°C |
| Mounting Type | Surface Mount |
| Package / Case | 16-SSOP (0.209", 5.30mm Width) |
