Semikron SEMIX303GB12E4S Trench IGBT Modules

Semikron SEMIX303GB12E4S Trench IGBT Modules



Part number  Brand Date QTY Package Remarks
SEMIX303GB12E4S Semikron 14+ROHS 7500 Module

Original have in  stock

PDF datasheet:

Features

• Homogeneous Si

• Trench = Trenchgate technology

• VCE(sat) with positive temperature coefficient

• High short circuit capability

• UL recognised file no. E63532

 Typical Applications*

• AC inverter drives

• UPS

• Electronic Welding

SPECIFICATIONS:

Mfr Package Description CASE SEMIX3S, 20 PIN
Status ACTIVE
Package Shape RECTANGULAR
Package Style FLANGE MOUNT
Terminal Form UNSPECIFIED
Terminal Finish NOT SPECIFIED
Terminal Position UPPER
Number of Terminals 8
Package Body Material UNSPECIFIED
Configuration SERIES CONNECTED, CENTER TAPPED WITH BUILT-IN DIODE AND THERMISTOR
Case Connection ISOLATED
Number of Elements 2
Transistor Application POWER CONTROL
Transistor Element Material SILICON
Channel Type N-CHANNEL
Transistor Type INSULATED GATE BIPOLAR
Turn-on Time-Nom (ton) 312 ns
Turn-off Time-Nom (toff) 663 ns
Collector Current-Max (IC) 466 A
Collector-emitter Voltage-Max 1200 V

Picture:
