NXP BLF6G27-10G BLF6G27 WiMAX power LDMOS transistor
| Part number | Brand | Date | QTY | Package | Remarks |
| BLF6G27-10G | NXP | 14+ROHS | 7500 | SOT-975C |
Original have in stock |
Features
Typical 1-carrier N-CDMA performance (Single carrier N-CDMA with pilot, paging,sync and 6 traffic channels [Walsh codes 8 - 13]. PAR = 9.7 dB at 0.01 % probability on CCDF. Channel bandwidth is 1.23 MHz), a supply voltage of 28 V and an IDq of 130 mA:
Qualified up to a maximum VDS operation of 32 V
Integrated ESD protection
Excellent ruggedness
High efficiency
Excellent thermal stability
Designed for broadband operation
Internally matched for ease of use
Low gold plating thickness on leads
Compliant to Directive 2002/95/EC, regarding Restriction of Hazardous Substances(RoHS)
| Datasheet | BLF6G27-10G |
|---|---|
| Packaging | Bulk |
| Transistor Type | LDMOS |
| Frequency | 2.5GHz ~ 2.7GHz |
| Gain | 19dB |
| Voltage - Test | 28V |
| Current Rating | 3.5A |
| Noise Figure | - |
| Current - Test | 130mA |
| Power - Output | 2W |
| Voltage - Rated | 65V |
| Package / Case | SOT-975C |
