NS FPD87352CXAVV FPD87352 Monitors and TV New in stock

NS FPD87352CXAVV  FPD87352 Monitors and TV New in stock

Features

Input frequency range from 30 MHz to 95 MHz

Support display resolutions XGA (1024x768), WXGA

(1280x768), HDTV I (1280x768), HDTV II (1366x768)

and HDTV - (1280x800)

Embedded gate array for custom panel timing

LVDS single pixel input (8-bit/6-bit) interface (FPD-Link)

RSDS dual bus output (8-bit/6-bit)

Drives RSDS column drivers up to 47.5 MHz clock

Flexible RSDS data output mapping for Bottom or Topmount

RTC (Response time compensation) function

2 Wired Serial EEPROM Interface support (RTC LUT)

Interface with external frame memory

Virtual 8-bit color depth in FRC/Dithering mode

Supports Graphics Controllers with spread spectrum

interface for lower EMI

Supports external Spread Spectrum (SSCG)

DE only mode

CMOS circuitry operates from 3.0V–3.6V; 0˚C–70˚C

176 LQFP package with body size 24 mm x 24 mm x1.4 mm, 0.5 mm pitch

Specification

Datasheet	FPD87352CXAVV
PLL	No
Main Purpose	Graphics Applications
Input	LVDS
Output	LVDS
Number of Circuits	1
Ratio - Input:Output	5:6
Differential - Input:Output	Yes/Yes
Frequency - Max	95MHz
Voltage - Supply	3 V ~ 3.6 V
Operating Temperature	0°C ~ 70°C
Mounting Type	Surface Mount
Package / Case	176-LQFP
