AD9142BCPZ AD9142 TxDAC Digital-to-Analog Converter New and original in stock
| Part number | Brand | Date | QTY | Package | Remarks |
| AD9142BCPZ | AD | 14+ROHS | 7500 | QFN |
Original have in stock |
FEATURES
Very small inherent latency variation: <2 DAC clock cycles
Proprietary low spurious and distortion design
6-carrier GSM ACLR = 79 dBc at 200 MHz IF
SFDR > 85 dBc (bandwidth = 300 MHz) at ZIF
Flexible 16-bit LVDS interface
Supports word and byte load
Multiple chip synchronization
Fixed latency and data generator latency compensation
Selectable 2×, 4×, 8× interpolation filter
Low power architecture
fS/4 power saving coarse mixer
Input signal power detection
Emergency stop for downstream analog circuitry
protection
FIFO error detection
On-chip numeric control oscillator allows carrier placement
anywhere in the DAC Nyquist bandwidth
Transmit enable function for extra power saving
High performance, low noise PLL clock multiplier
Digital gain and phase adjustment for sideband suppression
Digital inverse sinc filter
Supports single DAC mode
Low power: 2.0 W at 1.6 GSPS, 1.7 W at 1.25 GSPS, full
operating conditions
72-lead LFCSP
APPLICATIONS
Wireless communications: 3G/4G and MC-GSM base stations,
wideband repeaters, software defined radios
Wideband communications: point-to-point, LMDS/MMDS
Transmit diversity/MIMO
Instrumentation
Automated test equipment
| Datasheet | AD9142BCPZ |
|---|---|
| Settling Time | 20ns |
| Number of Bits | 16 |
| Data Interface | LVDS, Serial, SPI™ |
| Number of Converters | 2 |
| Voltage Supply Source | Analog and Digital |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Surface Mount |
| Package / Case | 72-VFQFN Exposed Pad, CSP |
| Supplier Device Package | 72-LFCSP-VQ (10x10) |
| Number of Outputs and Type | 2 Current |
| Sampling Rate (Per Second) | 1.6G |
