BCM7405CNKFEBA03G BCM7405 CABLE DVR SET-TOP BOX

BROADCOM BCM7405CNKFEBA03G BCM7405 CABLE DVR SET-TOP BOX New in stock

Feature:

• HD/SD H.264/AVC Main and High Profile to Level 4.1 (HD), Level 3.1 (SD)

• HD/SD AVS Jizhun Profile Levels 2.0, 4.0, and 6.0 (720p and 1080i for HDTV)

• VC-1 Advanced Profile @ Level 3, Simple and Main Profile

• HD/SD MPEG-2 Main Profile at Main and High levels

• MPEG still image decode

• SD MPEG-4 P2 SP/ASP • HD DivX 3.11/4.11/5.x/6x/Home Theater

• Advanced audio processor supporting the following:

• AAC LC, AAC LC+SBR Level 2, AAC+ Level 2, AAC-HE

• Dolby® Digital, Dolby Digital Plus

• MPEG I layers 1, 2, and 3 (MP3)

• Windows Media®and Windows Media Pro audio

• One pair of on-chip stereo high-fidelity audio DACs

• 3D SRS audio support

• One I2S input port and one I2S output port, plus S/PDIF output

• High-performance 2D-effects graphic engine

• Studio-quality text and graphics at HD resolution

• Supports multiple layers and windows

• Digital noise and contour reduction (DNR/DCR)

• Reduces artifacts such as block/mosquito noise

• Picture-in-picture

• Supports simultaneous HD+SD display

• Mosaic Mode

• Supports up to 16 video decode/display for video-rich navigation

• Motion-adaptive deinterlacer with reverse 3:2/2:2 pulldown

• OpenCable™ ready with on-chip MPOD support

• 400-MHz Dual-Core CMT MIPS32®/16e class processor

• 64-bit DDR2 DRAM controller

• Dual SATA-2 interfaces for DVR and DVD applications

• HD analog video encoder with simultaneous SD outputs

• NTSC-M/J, PAL-BDGHIN/M/Nc, SECAM analog outputs

• 480i/480p/576i/576p/720p/1080i output formats

• Component RGB/YPrPb HD/HD-DVO outputs

• Macrovision® 7.1/NICAM support

• SCART 1 and 2

• Component, S-Video, and composite via six on-chip V-DACs

• VBI encoders for CC/TTX with NABTS/CGMSA/WSS/

Gemstar®, AMOL I/II standards and dedicated TTX sideband

• RF modulator with BTSC encoder

• ITU-R-656 input and output ports

• HDMI 1.3/DVI 1.0 Mac and PHY with HDCP 1.1

• Broadcom security processor

• AES/1DES/3DES/CSS/CPRM/DTCP copy protection

• MPEG-2/DIRECTV/DVB/ARIB data transport demux with

1DES/3DES/DVB/Multi2/AES descramblers

• V.92-capable soft modem with integrated SiLab Si305x system side device

• Dual USB 2.0 host controller with host transceiver

• Additional host/client USB 2.0 controller/transceiver

• Dual Ethernet MACs with integrated single PHY and MII

• UHF remote control receiver

• Dual SmartCard support
