ATTINY2313A-SU ATTINY2313A 8-bit Microcontroller

ATTINY2313A-SU ATTINY2313A 8-bit Microcontroller with 2/4K Bytes In-System Programmable Flash

Features

• High Performance, Low Power AVR® 8-Bit Microcontroller

• Advanced RISC Architecture

– 120 Powerful Instructions – Most Single Clock Cycle Execution

– 32 x 8 General Purpose Working Registers

– Fully Static Operation

– Up to 20 MIPS Throughput at 20 MHz

• Data and Non-volatile Program and Data Memories

– 2/4K Bytes of In-System Self Programmable Flash

• Endurance 10,000 Write/Erase Cycles

– 128/256 Bytes In-System Programmable EEPROM

• Endurance: 100,000 Write/Erase Cycles

– 128/256 Bytes Internal SRAM

– Programming Lock for Flash Program and EEPROM Data Security

• Peripheral Features

– One 8-bit Timer/Counter with Separate Prescaler and Compare Mode

– One 16-bit Timer/Counter with Separate Prescaler, Compare and Capture Modes

– Four PWM Channels

– On-chip Analog Comparator

– Programmable Watchdog Timer with On-chip Oscillator

– USI – Universal Serial Interface

– Full Duplex USART

• Special Microcontroller Features

– debugWIRE On-chip Debugging

– In-System Programmable via SPI Port

– External and Internal Interrupt Sources

– Low-power Idle, Power-down, and Standby Modes

– Enhanced Power-on Reset Circuit

– Programmable Brown-out Detection Circuit

– Internal Calibrated Oscillator

• I/O and Packages

– 18 Programmable I/O Lines

– 20-pin PDIP, 20-pin SOIC, 20-pad MLF/VQFN

• Operating Voltage

– 1.8 – 5.5V

• Speed Grades

– 0 – 4 MHz @ 1.8 – 5.5V

– 0 – 10 MHz @ 2.7 – 5.5V

– 0 – 20 MHz @ 4.5 – 5.5V

• Industrial Temperature Range: -40°C to +85°C

• Low Power Consumption

– Active Mode

• 190 µA at 1.8V and 1MHz

– Idle Mode

• 24 µA at 1.8V and 1MHz

– Power-down Mode

• 0.1 µA at 1.8V and +25°C

Picture：
