TOSHIBA TPH1R403NL MOSFET X35PBF Power MOSFET Transistor

Features


FEATURES

Product Category:    MOSFET

RoHS:   RoHS Compliant Details

Technology: Si

Mounting Style:  SMD/SMT

Package / Case: SOP-8

Number of Channels:     1 Channel

Transistor Polarity:   N-Channel

Vds - Drain-Source Breakdown Voltage:    30 V

Id - Continuous Drain Current:     60 A

Rds On - Drain-Source Resistance:     1.4 mOhms

Vgs - Gate-Source Voltage:   20 V

Vgs th - Gate-Source Threshold Voltage:  1.3 V to 2.3 V

Qg - Gate Charge:    46 nC

Maximum Operating Temperature:    + 150 C

Packaging:   Reel

Channel Mode:   Enhancement

Brand:   Toshiba

Configuration:    Single

Minimum Operating Temperature:     - 55 C

Pd - Power Dissipation:   64 W

Series:  TPH1R403NL

Factory Pack Quantity:   5000

Transistor Type: 1 N-Channel

Unit Weight: 0.030018 oz
