TPD4111K High Voltage Monolithic Silicon Power IC

Features


FEATURES

Bootstrap circuit gives simple high-side supply.

Bootstrap diode is built in.

PWM and 3-phase decoder circuit are built in.

3-phase bridge output using IGBTs.

Outputs Rotation pulse signals.

FRDs are built in.

Incorporating over-current and under-voltage protection, and

thermal shutdown.

Package: 23-pin HZIP.

Compatible with Hall amp input and Hall IC input.

Applications

It is easy to control a DC brush less motor by applying a signal from a motor controller and a Hall amp/ Hall IC
