CYWB0124AB-BVXI USB, Memory Card Controller USB 2.0 Parallel Interface

Features


Features

SLIM architecture, enabling simultaneous and independent

data paths between processor and USB, and between USB

and mass storage

High speed USB at 480 Mbps

USB-2.0 compliant

Integrated USB 2.0 transceiver, smart serial interface engine

16 programmable endpoints

Mass storage device support

MMC/MMC+/SD/CE-ATA

NAND flash: x 8 or x 16, SLC

Full NAND management (ECC, wear leveling)

Memory mapped interface to main processor

DMA slave support

Supports Microsoft® media transfer protocol (MTP) with

optimized data throughput

Ultra low power, 1.8 V core operation

Low power modes

Small footprint, 6 x 6 mm VFBGA, and less than 4 x 4 mm WLCSP

Selectable clock input frequencies

19.2 MHz, 24 MHz, 26 MHz, and 48 MHz

Application

Cellular phones

Portable media players

Personal digital assistants

Digital cameras

Portable video recorder
