Manufacturer Part |
|
IC MOTOR DRIVER PAR 8SOP Motor Driver Bipolar On/Off 8-SOP |
|
Audio-visual equipment PC peripherals Car audios Car navigation systems OA equipments |
|
Datasheet |
Details |
Description The reversible motor driver for output 1.0A for 1 motor can set the output modes to four modes, normal, reverse, stop(idling), and braking in accordance with logic input (2 inputs).
Features Built-in surge absorption diode By built-in power save circuit, current consumption when a motor stops (idles) can be suppressed Output voltage can be optionally set by reference voltage setting pin Built-in thermal shutdown circuit (TSD)
Product Category:Motor / Motion / Ignition Controllers & Drivers Manufacturer:ROHM Semiconductor RoHS:RoHS Compliant Details Product:Brushed DC Motor Drivers Type:Reversible Motor Driver Operating Supply Voltage:4.5 V to 15 V Output Current:1 A Operating Supply Current:24 mA Minimum Operating Temperature:- 20 C Maximum Operating Temperature:+ 75 C Mounting Style:SMD/SMT Packaging:Reel Packaging:MouseReel Packaging:Cut Tape Brand:ROHM Semiconductor Operating Temperature Range:- 20 C to + 75 C Series:BA6287F Factory Pack Quantity:2500 Unit Weight:0.030018 oz |
