Manufacturer Part |
|
Amplifier IC 4-Channel (Quad) Class D PowerSO-36 EPU |
|
The device can be used as a dual bridge or reconfigured, by connecting pin CONFIG to pins VDD, as a single bridge with double-current capability |
|
Datasheet |
Details |
Standard Package 1,000 Packaging Tape & Reel (TR) Part Status Active Type Class D Output Type 4-Channel (Quad) Max Output Power x Channels @ Load 10W x 4 @ 4 Ohm Voltage – Supply 10 V ~ 36 V Features Short-Circuit and Thermal Protection Mounting Type Surface Mount Operating Temperature 0°C ~ 70°C (TA) Supplier Device Package PowerSO-36 EPU Package / Case 36-BSSOP (0.433", 11.00mm Width) Exposed Pad
Features Multipower BCD technology Low input/output pulse width distortion 200 m RdsON complementary DMOS output stage CMOS-compatible logic inputs Thermal protection Thermal warning output Undervoltage protection Short-circuit protection
The STA515W is a monolithic quad half-bridge stage in Multipower BCD Technology. |
