Manufacturer Part |
|
|
Analog to Digital Converters - ADC 2CH 2.35-5.25V 250 kSPS 12-Bit |
|
|
Battery-powered systems: Personal digital assistants Medical instruments Mobile communications Instrumentation and control systems Data acquisition systems High speed modems Optical sensors |
|
|
Datasheet |
|
Details |
|
FEATURES Fast throughput rate: 250 kSPS Specified for VDD of 2.35 V to 5.25 V Low power: 4 mW typ at 250 kSPS with 3 V supplies 13.5 mW typ at 250 kSPS with 5 V supplies Wide input bandwidth: 71 dB minimum SNR at 100 kHz input frequency Flexible power/serial clock speed management No pipeline delays High speed serial interface: SPI®/QSPI™/MICROWIRE™/DSP compatible Standby mode: 1 μA maximum 8-lead TSOT package 8-lead MSOP package
The AD7911/AD79211 are 10-bit and 12-bit, high speed, low power, 2-channel successive approximation ADCs, respectively.The parts operate from a single 2.35 V to 5.25 V power supply and feature throughput rates of up to 250 kSPS. |
