ROHM BA4558F BA4558F-E2 Low Noise Operational Amplifiers
| Part number | Brand | Date | QTY | Package | Remarks |
| BA4558F | ROHM | 14+ROHS | 7500 | SOP-8 |
Original have in stock |
Features
High voltage gain, low noise, low distortion
Wide operating supply voltage
±4.0[V]～±15.0[V]( split supply)
(BA4560/BA4558/ BA4558R/BA4560R/BA4564R family)
±2.0[V]～±16.0[V]( split supply)
(BA4580R/ BA4584/BA8522R/BA15218 family)
±2.0[V]～±8.5[V]( split supply)(BA4584R family)
±2.0[V]～±18.0[V]( split supply)(BA14741 family)
±3.0[V]～±20.0[V]( split supply)(BA15532 family)
±1.0[V]～±3.5[V]( split supply)(BA4510 family)
±1.0[V]～±7.0[V]( split supply)(BA2115 family)
Internal phase compensation
No latch up immunity
Internal ESD protection
Human body mode (HBM) ±5000[V](Typ.)
(BA4558R/BA4560R/BA4564R/BA4580R/BA4584/ BA4584R/BA8522R/BA2115 family)
Wide temperature range
-40[℃]～+85[℃]
(BA4558/BA4560/BA4584/BA15218/BA14741/BA2115 family)
-40[℃]～+105[℃]
(BA4558R/BA4560R/BA4564R/BA4580R/BA4584R/BA8522R family)
Specification
| Datasheet | BA4558F |
|---|---|
| Amplifier Type | General Purpose |
| Number of Circuits | 2 |
| Output Type | - |
| Slew Rate | 1.2 V/µs |
| Gain Bandwidth Product | 2MHz |
| -3db Bandwidth | - |
| Current - Input Bias | 60nA |
| Voltage - Input Offset | 500µV |
| Current - Supply | 3mA |
| Current - Output / Channel | 10mA |
| Voltage - Supply, Single/Dual (±) | 8 V ~ 30 V, ±4 V ~ 15 V |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Surface Mount |
| Package / Case | 8-SOIC (0.173", 4.40mm Width) |
